BSR-5V1000 | Chromatography Cabinet

A chromatography cabinet is a special purpose refrigerated container developed specifically for biochemical chromatography experiments,

Can be used for experiments that require low-temperature environments, as well as for refrigeration of items.

Product Usage:

The chromatography cabinet is a special purpose low-temperature cabinet developed specifically for biochemical chromatography experiments, and can also be used for other experiments that require low-temperature environments or for refrigeration of items.

Structural design:

1. The overall box body is made of high-quality cold-rolled steel plate, and the surface is treated with environmentally friendly pottery and spraying technology.

Temperature control:

1. Temperature controller: placed on the top of the box, touch the color screen, display content: real-time temperature, background settings, mute, lighting, UV light;

2. Accurate electronic temperature control, with a display accuracy of 0.1 ℃;

*3. Standard USB storage module, capable of storing 8000 records per month, with a maximum storage capacity of 10 years (120 months) of data. After exceeding the limit, the data will be rolled over and overwritten;

4. The refrigeration layout ensures that the temperature inside the box remains stable within the range of 2 ℃ to 8 ℃;

5. Reliable temperature control provides the storage environment required for reagents, drugs, and samples.

Refrigeration system:

*1. Internationally renowned brand compressor, fluorine free environmentally friendly and efficient refrigerant, fast cooling speed, high cooling efficiency, low power consumption;

*2. The air-cooled finned evaporator, combined with a unique circulating air cooling system design, ensures a constant temperature inside the refrigerator;

*3. The high-density insulation foam layer uses environmentally friendly cyclopentane foaming agent, which has good insulation effect.

Security guarantee:

1. Equipped with high and low temperature alarm, sensor fault alarm, and abnormal door opening and closing alarm functions inside the box;

2. Equipped with sound buzzer alarm mode;

3. Sensor malfunction safe operation mode (display sensor and control sensor are backup to each other);

4. Temperature controller keyboard lock and password protection function to prevent arbitrary adjustment of operating parameters;

5. Power outage protection: The refrigerator has a delayed start function to prevent multiple devices from causing circuit breaker protection when the power grid is restored. user-friendly design

1. Safe door lock design ensures the safety of stored items;

2. Digital display facilitates observation;

3. Standard test holes for easy monitoring or experimental data collection by users;

4. Height adjustable shelf design, adjusting the height according to different items to improve space utilization;

5. Universal brake wheel design, convenient for users to move devices;

*6. Double layered hollow electric heating membrane glass door, with no condensation during equipment operation;

7. Built in LED energy-saving lighting, automatically turns on or off when opening or closing the door, making it easy to observe the contents inside the boxproduct

8. One side shelf, adjust the shelf height according to different items to improve space utilization;

9. Reserve space on one side for the placement of the chromatography instrument, and make reasonable use of the space according to the size of the chromatography instrument. Standard configuration includes one chromatography column fixing and clamping device;

10. Built in UV disinfection lamp, which can be controlled by both door signal and UV switch button;

11. There are 2 built-in waterproof sockets, which facilitate the power supply of instruments for chromatography experiments.
