1 Scope of application
The refrigerated compartment is used to provide a storage environment of 2 ℃~8 ℃, while the freezer compartment is used to provide a storage environment of -10 ℃~-40 ℃
For medical institutions to store samples such as reagents, vaccines, frozen plasma, etc.
Structural design:
1. The outer box is made of high-quality cold-rolled steel plate, and the surface is treated with environmentally friendly pottery and spraying technology. The inner box is made of international standard SUS304 stainless steel.
Temperature control:
1. Adopting a microcomputer control system with temperature digital display to ensure stable operation;
2. Refrigeration and freezing independently display temperature, with a display accuracy of 0.1 ℃;
3. Refrigeration and freezing independent refrigeration system, refrigeration compartment 2 ℃~8 ℃, freezing compartment -10 ℃~-40 ℃;
4. Provide the storage environment required for reagents and samples.
Refrigeration system:
*1. Internationally renowned brand compressor, environmentally friendly and efficient hydrocarbon refrigerant, fast cooling speed, high cooling efficiency, low power consumption;
*2. The copper tube aluminum fin evaporator in the refrigeration compartment is designed with a back blowing circulating air cooling system to ensure a constant temperature inside the refrigerator;
*3. The evaporator in the freezer adopts high-efficiency copper tubes for heat transfer, which are embedded in the inner box wall for conduction cooling, saving internal space;
*4. EBM brand condensing fan, energy-saving and efficient, with reliable performance;
5. The high-density insulation foam layer uses environmentally friendly cyclopentane foaming agent, which has good insulation effect.
Security guarantee:
*1. Equipped with high and low temperature alarm, sensor fault alarm, power outage alarm (supporting 72 hours), and abnormal alarm function for independent opening and closing of refrigeration and freezing doors inside the box;
*2. Equipped with dual alarm modes of sound buzzing and light flashing;
*3. Temperature controller measuring point fault safe operation mode (display sensor and control sensor are backup to each other);
*4. Password protection function to prevent arbitrary adjustment of operating parameters;
*5. Power outage protection: delayed start function to prevent multiple devices from starting simultaneously and causing circuit breaker protection when the power grid is restored.
user-friendly design
*1. The refrigeration and freezing compartments are designed with dual locks, using a tight handle design and can be equipped with padlocks to ensure the safety of stored items;
2. Digital display facilitates observation;
3. Standard test holes for easy monitoring or experimental data collection by users;
*4. Height adjustable shelf design, adjusting the height according to different items to improve space utilization;
5. Universal brake wheel design, convenient for users to move devices;
*6. The double-layer insulated tempered glass foam door in the refrigeration room is heated with electricity to prevent surface condensation and achieve better display effect;
*7. The double-layer door seal and inner and outer door design of the freezer lock the cold air to prevent leakage, resulting in a more uniform temperature and more energy-efficient products.
