BBR-4V136 | Medical Blood Refrigerator

Medical blood refrigerators are mainly used to store whole blood, red blood cells, biological products, vaccines, special reagents, etc. They are a professional storage device. Widely used in blood stations, hospitals, and diseases

Prevention and control centers, animal husbandry, scientific research institutions, electronics, chemical industry and other industries.

Structural design:

*1. The outer shell of the box is made of high-quality cold-rolled steel plate, which has undergone environmental protection, purification, spraying and other processes, and has strong corrosion resistance;

*2. The inner box is made of SUS304 stainless steel plate;

*3. Foam door body, better insulation effect;

Temperature control:

1. Adopting a microcomputer control system with temperature digital display to ensure stable operation;

*2. Accurate electronic temperature control, display accuracy up to 0.1 ℃, temperature sensing box design, simulating the true temperature inside the blood bag;

3. Temperature setting deviation protection to avoid misoperation;

*4. Equipped with a thermal printer as standard, it can print temperature data in real-time or periodically;

*5. Cold air back blowing design, the temperature inside the box is stable within the range of 4 ± 2 ℃;

6. Reliable temperature control provides the storage environment required for reagents, drugs, and samples.

Refrigeration system:

*1. Internationally renowned brand compressor, fluorine free environmentally friendly and efficient refrigerant, fast cooling speed, high cooling efficiency, low power consumption;

*2. The copper tube aluminum fin evaporator, combined with a unique circulating air cooling system design, ensures a constant temperature inside the refrigerator;

*3. The high-density insulation foam layer uses polyurethane cyclopentane foaming agent, which has good insulation effect.

Security guarantee:

*1. Equipped with high and low temperature alarm, sensor fault alarm, power outage alarm (supporting 72 hours), and abnormal door opening and closing alarm functions inside the box; Equipped with dual alarm modes of sound buzzing and light flashing;

*2. Temperature controller measuring point dual display dual control operation mode;

*3. Password protection function to prevent arbitrary adjustment of operating parameters;

*4. Power outage protection: The refrigerator has a delayed start function to prevent multiple devices from starting simultaneously and causing circuit breaker protection when the power grid is restored.

user-friendly design

1. Input voltage: 220V to ± 10%;

*2. Safe door lock design to prevent unauthorized opening and ensure safer storage of items;

3. Digital display facilitates observation;

*4. Standard test holes are provided for easy monitoring and data collection by users during experiments;

5. Adjustable shelf height design, suitable for storing items of different heights;

6. Universal caster design, convenient for users to move devices;

*7. High density foam layer door body combined with hollow tempered glass door, electric heating anti condensation design, excellent display effect;

*8. The outer door is equipped with a self rebound device to prevent users from forgetting to close the door or not closing it tightly after picking up items.

*9. Independent and transparent inner door design ensures cooling loss * * when opening the door, saving energy and reducing consumption;

10. Built in LED energy-saving lighting, convenient for observing items inside the box.
